• Overall size 23” (W) x 21.50” (D) x 10.25 ” (H)
• Power ratings: 115V / 1 / 60 Hz, 1.1 Amp., Standby current is 7W only
• Washable Polypropylene core and Filters
• High-efficiency energy-saving permanently lubricated
variable speed PSC motors for air balancing
• Suitable for horizontal & vertical installation
• Tilted core design for maximum efficiency
• Automatic fan cycled defrost
• Exhaust up to three washrooms
• Two Speed exhaust (High / Low) – up to 165 CFM

• Continuous fresh air supply at Normal speed up to 140 CFM

• Furnace / Fan-coil / Heat Pump Interlock

• Dual Protection: If the exhaust fan fails, the outside fresh-air supply will be closed
by shutting off supply motor and the relay contact for motorized damper and
the interlock will be opened. Fan Coil/Furnace low speed will be stopped and at
normal operation no air will enter into the system

• In case of power failure, optional motorized spring return damper
stops the fresh air intake and prevent core from freezing
• Weight approximately 60 lbs., 2 years warranty on parts
